HV combined filter/FFU filter

HV combined filter/FFU filter

◆ V type low pressure loss filter

◆ No partition design, super-fine glass fiber filter paper

◆ High dust holding capacity, low resistance and long service life

◆ Firm structure, ensure good performance under the condition of turbulence

◆ Polypropylene plastic frame, can be completely incinerated and disposed of


0.00
0.00

Product Description

◆ V type low pressure loss filter

◆ No partition design, super-fine glass fiber filter paper

◆ High dust holding capacity, low resistance and long service life

◆ Firm structure, ensure good performance under the condition of turbulence

◆ Polypropylene plastic frame, can be completely incinerated and disposed of


Efficiency
◆ Medium efficiency：F6~F9(EN779)
◆ Sub efficiency：H10~H12
◆ High efficiency：H13~H14
Application
◆ High temperature ,variable intake air conditioning system
◆  Pharmaceutical factory , clean room, efficient air supply, internal use
◆ Clean room FFU products supporting efficient filter

Material and working condition

Frame

Plastic/ zinc coating

Filter Material

Super fine glass fiber

Partition material

Melt adhesive

Sealant

Polyurethane

Working maximum temperature

80 ℃

Working maximum humidity

100%


Specification

Model

External Size

(W*H*Dmm)

Rated air flow

m³/h

Face velocity

m/s

Filtering area

㎡

Initial resistance

Pa

Efficiency

(MPPS)

Dust Capacity

(g)

HV

292*592*292*4V

1000

2.0

7.0

≦250

≥99.9995%

220

492*592*292*5V

1500

2.0

10.6

450

610*610*292*4V

2100

2.0

10.5

650

610*610*292*5V

2700

2.0

15.8

300

610*610*291*6V

3300

2.0

20.5

600
